Refurbishing / Replacing the Subwoofer (Post #633) 11/26/2023

Subwoofer work

Ever wonder what is inside of that gigantic custom-fit subwoofer box in the back of your Range Rover Classic…well wonder no more. I had to pull all the parts of the sound system out of the Big White Bus to investigate my rust issues.

It takes a few bolts to get it out but everything is easy-ish to get to and you don’t need any special tools. Take the amplifier off the subwoofer box. Then tackle all the bolts. Once the subwoofer is out you can get to the antique CD changer. Actually in 1993 a six disc CD changer was straight up gangster. My CD changer worked for a few years. It then got a little buggy. You could get it to work if you slid it out and slammed it back in. Most of the time it started to be available at the head unit after that.

It all has to come out. I have a new head unit. I have new speakers. I don’t know if the amplifier still works. I will have to sit down at some point and try to figure out all the plugs and see if the amplifier will be part of the equation. Having a working subwoofer would be a nice addition.

Once the subwoofer is out it takes 10 screws and a little gentle encouraging and the box will come apart. It’s a relatively simple setup. There is a dual cone speaker inside and that’s it. Mine as you will see in the video is toast. the cone has disintegrated. It is at least 30 years old probably closer to 33 considering assembly line technology of the day.

So the speaker will need to be replaced. In the video I speculate about the size but it turns out to be:

  • Cutout Diameter 6.5 inches
  • Top Depth mounting 3 inches
  • Bottom Depth Mounting 3.25
speaker measuring graphic

There are a LOT of speakers to choose from online. I went to Crutchfield.com. They don’t sponsor me, I wish they did, but they don’t. They have great customer service and the spec’s for everything are easy to find on their site.

I found a speaker that looks like it will fit.

That’s not a lot of money and 4 people think it’s pretty awesome. Mounting that is still a question, but I’m not worried. I will figure it out if that is the direction I go.

There is some debate going on in my head about replacing the old one with a NEW subwoofer. I found a Kenwood on Crutchfield that was not all that expensive.

Kenwood Excelon
ribbed polypropylene cone, sounds naughty….

It’s pretty small too. Just a little under 18x12x6 inches. I’m certain I’d have to cover the speaker cause it would almost certainly get damaged if I didn’t. I am confident it would fit in the space. But the real question outside of would it be better is…. am I really saving enough space to matter? I’m not sure I would gain anything. The space would have to be VERY creatively designed to take advantage of a few inches more here or there.

This gives us the cheaper option of just buying the speaker and figuring out how to wire it to the old AMP and the new head unit. Another plus of this operation was the elimination of the CD player gives me 12 volt switched power line back in that corner. That might come in handy, who knows.

I like tunes as much as the next guy. I even have a playlist named, “Can’t Be Too Loud”. It’s got some songs that you turn up until your ears bleed.

  • Van Halen’s Eruption
  • AC/DC Back In Black
  • Living Colour’s Cult of Personality
  • Beastie Boys Sabotage
  • Black Sabbath’s Iron Man
  • Wagner’s Die Walküre (Ride of the Valkyrie)
  • Carl Orff’s O Fortuna from Carmina Burana

There are more, but you get the picture…you probably have a list of your own. Whenever I hear these songs I turn them up to maximum volume.

Mostly today…I listen to audio books. Sooooo many audio books. It’s not uncommon for me to just drive, no music, just the window down and the sound of the engine and the tires on the road. That recharges my batteries almost as just sitting in the woods next to a fire.

There is a lot left to do to get the sound system installed. I’ve got to sort out the plugs and get everything wired up. The dash is still not installed. There is an order to putting the BWB back together…and the windshield needs to be first. I’m almost certain there is water leaking in and the last thing I want is to get his all put back together and still having water coming in.

That’s it for this week. As soon as I make a decision I’ll post it up and when I starting putting the sound system together.

Your sponsorship on Patreon would be appreciated if that is in your budget. Otherwise LIKE and SUBSCRIBE to the YouTube channel. Leave me a comment…I love talking to people about Land Rovers.

Thanks for reading and Happy Rovering.

https://youtu.be/WbGtqSa13cw

Passenger Side Rear Wheel Well Rust – Part 2: Investigation (Post #632) 11/20/2023

thumbnail

I have official started the rust abatement on the passenger side rear wheel well. I’ve looked at it and took the stone chip back and overall, it’s not nearly as bad as the driver’s side.

I think it will not take too much to get this side repaired. Just 8 small spots of rust that will require patches.

I should have done more research. I didn’t account for the fuel filling hoses when I took the fender off. I didn’t need to remove the hoses. The top of the filler was only in place by a rather badly deteriorating rubber gasket. Which, as of this post, I have not found a replacement for. Also in doing this, I’ve decided it would be easier to replace the filler hoses than reinstall. They are 30+ years old and quite hard.

I found one hose on Rover’s North but the second smaller one I did not find. I may just take a sample of each and go down to O’Reilly’s and find the equivalent size hose from the “WALL OF HOSES”. They are usually pretty good about letting me go back there and matching up. If I secure hoses with this method I’ll put the part numbers in this post.

Next up will be cutting and welding the bits. I took the subwoofer out as it was in the way. The speaker inside was perished. I looked on line and found some comparable speakers. They look to be 6.5 inches in diameter and 3.5 inches in depth. I think I can replace it for as low as $90.00(US). I could spend WAY more, but I don’t see the point. I mostly listen to books on tape, books on CD, audiobooks when I drive. When I overland, more often than not, I just listen to the wind and the engine while I’m bopping down the backroads.

Thanks for reading and Happy Rovering.

okierover.com/patreon

Like and subscribe if you find this content entertaining and informative.

Passenger Side Rear Wheel Well Rust – Part 1 (Post #631) 11/14/2023

rats

Now that I have the Range Rover flopped in the shoppe I can start on the rust abatement. But first, I thought I should get some oil and some other fluids and do some fluid refreshing. That was a great idea if I had done that BEFORE I started the Big White Bus. But the fact I was doing it AFTER I ran the engine, -2 points.

I loaded up one 5 gallon barrel of oil and headed to my favorite O’Reilly’s. When I got out of the truck my folly was apparent. I had successfully done an Exxon Valdez [Wikipedia] imitation. The metal barrel had rusted through the bottom and dropped 5 gallons of used oil all over the back of my F-150 and on to their Prince William Sound parking lot. I ran in and bought two bags of kitty litter/oil soaker stuff and with the help of one of the guys we spread all that all over their parking lot. I haven’t been that embarrassed in a long time.

I finished up the clean up of the back of my F-150 when I got home and started getting the rear passenger wheel off to start the investigation. The video shows I had a mostly optimistic view when I started scraping the rust. In comparison…the passenger side is no where near as bad as the drivers side wheel well. The rear window is another issue entirely but let me attack these one at a time.

I’ve got two holes SO FAR. I still have to get the wire wheel out and take the rubber back to metal where there are brown spots. The worst looking SO FAR is the bottom of the C Pillar is rusted out. The reason for the rust there is the sunroof drain hose exits there and the crappy plastic grommet did not keep water out. And it is entirely likely that there was nothing inside the C Pillar that would pass for paint. So that was an obvious place for rust.

I’m going to replace the sunroof drain tubing and possibly fit a “Hose Barb Thru-Bulk Head Hex Union 90 Degree L Right Angle Elbow Barbed Brass Fitting with Flat Washer Gasket Water/Fuel/Air” fitting. Something like this….

I’ll add a rubber washer to assist in keeping the water out. I’ve got to measure the tubing and get the right one ordered. They can be found on Amazon.com. Not sure if they are using ID (inside diameter) or OD (outside diameter) to determine if I get 3/8″ or 1/2″.

This may be complete folly but what the hell right? If it works, I’m a genius. If it doesn’t work, I’m still a genius, just a terribly misguided one. Half of me says extend the drain line to behind the mudflap. It would not be that hard to add a little more distance to the hose and NOT put it back in the same poorly designed place. I mean seriously, lots of water and ice and mud and road salt and roadkill chunks (mostly opossums and armadillos and skunks) and all kinds of crap fly off the tires at extreme tangential velocity [Study.com]. The fact that plastic gromet is even able to not be dislodge is a miracle. So…let’s try to make it better!

The headline came out also so I could get the sunroof drain. It had to come out anyway, because it needed to be replaced…again. This will be the third and final. If this is needed again while I own this rig, it will be painted and forgotten.

More next week. Like and subscribe my Youtube channel. Send me a comment too…I love to converse with you.

Thanks for reading and Happy Rovering.

patreon.com/okierover

Starting and Moving the Big White Bus (Post #630) November 6, 2023

holding a spark plug

This weekend I had to get the Big White Bus running so I could turn her around in the shoppe bay. This required me to reinstall the spark plugs and fashion some kind of a temporary seat.

The plugs went in just fine. I applied a new coat of copper anti-seize. It’s time to buy some more as the tube I have is getting a bit dry. But it was sufficiently lube-y to pass for grease.

I got all the plugs in and the wires on without an issue. I got the coil hooked back up. I then stared at the engine bay to confirm everything was ready to go.

Next I needed a seat. I had a lovely 12 inch wide, 16 inch long pine board that covered the electronics and made a lovely “field expedient” seat. And I was ready to start her up…..

….then the GoPro decided to stop recording. Right when I needed it to be recording…it wasn’t. Heavy sigh.

So everyone misses out on the magic moment. Typical.

I turned the key and heard the fuel pump do it’s initial pump. I turned the key and she fired up as expected. Victory! Well, a battle was won, let’s just leave it at that.

I moved all the flotsam and jetsam from around the Range Rover and moved the F-150. I jumped in and drove her up the drive way, made a flawless, 4 point turn :/ and brought back down to the shoppe. The windshield was so dirty I had to clean in order to see how to line her up in the bay.

My daughter RovErica left me a sweet message on the windshield the last time she was home visiting. I left the side with the message undisturbed.

Now the BWB is flipped around. I can now begin to abate the rust on that side. HOPEFULLY these repairs will not be as extensive as the driver’s side. The driver’s side has been the side with the most trauma from being rear-ended by inattentive drivers. My welder and the power for that welder are on that side of the shoppe so turning her around was required.

That’s all I’ve got for this week. Like and subscribe the YouTube video. Comment if you like too…I love to hear from my readers. I also have a Patreon that sadly has NO current membership. Every little bit helps and if you feel my content is worthy of a couple of bucks a month…I promise not to spend it on rum.

Thanks for reading and Happy Rovering.

https://youtu.be/KM3RCtc7gm8

A Visit to the Air Defense Training Facility (Post #629) October 29, 2023

Half track

I was invited by my friend Correy Twilley to come to Fort Sill and participate in a WW2 living history event. The plan was to take the M3 Half Track and a Jeep with a Pack 75 howitzer out to the field and and have students and family come by and learn some history. Unfortunately the weather for Saturday would be pretty nasty. For dedicated living historians that’s not a big deal but the purpose was to have visitors. Not likely to have many visitors when the north wind blows in the 20mph range, rain falling, and temps in the middle 30’s Fahrenheit (1 to 5 Celsius).

World War 2 is not one of my current periods. I would have had to borrow my entire kit. But Correy said not a problem, so I said, “let’s do it”. When he cancelled I told him I still had the day off and would like to come down and visit the training facility.

If you are following the news, they are deploying some anti-aircraft units from Fort Sill to the Middle East. So I was at first concerned I would be in the way. Turned out not to be a problem as most of the troops were already getting their trashed gather up for deployment. Correy taught a class that morning and had a meeting but the afternoon was available for us to tour the displays.

Friday was pleasant with sunny skies so I toured the gun park. There were several examples of weapons I trained on in the park.

I trained on the M101A4 at artillery school. Fort Sill is home to the Artillery School now, but when I served there were two schools, Camp Pendleton and Camp Lejeune. They sent me to Las Pulgas, Camp Pendleton.

After school I was assigned to 5th Battalion, 14th Marines, Oscar Battery. We were using the M110A2 howitzer. This beast was a very accurate system and nuclear capable.

In the infinite wisdom of the Corps they sent our M110s to California changed our unit designation to 2nd Battalion, 14th Marines, Fox Battery. These towed behemoths required modern trucks (M939) to pull them. I was not a fan.

When Correy was finished with his classes he gave me a tour of the training facility. As you will see in the video, they have an amazing collection. Several of the systems are 1 of a kind or there are less than 3 of these known to exist. Several of the trucks and Jeeps are near fully functional and could be taken out if a little work was done on them. Several of the systems are demonstrated for students with live fire exercises.

As promised, Correy said we would take the M16 Half-track out for a spin. It is an M3 based Multiple Gun Motor Carriage equipped with the Maxson M45 Quadmount (specifically the M45D) with four M2HB machine guns. Our first stop was to drive it to the gas station and put in a couple of gallons. The looks on people’s faces when you roll up to the station is pretty fun. After that we took it over to Medicine Man Bluff and then around the old post and finally back to the museum.

I’m looking forward to the next opportunity to go down to the base and to go out in the field with my friends. The weather has turned cold. Seems like we skipped Fall all together this year and went from 90’s to 30’s Fahrenheit in two days.

Thanks for your patience while we went to St. Croix for a week. We needed the break and took a lazy week to recover from work and life. I did manage to see 5 Land Rovers on the island. You can see them on my Instagram account.

I’m working on the backup fuel pump and plan to get the BWB started and turned around in the shop. That will allow me to tackle the rust on the passenger (starboard) side. I’ll have another video up next week.

Like and or subscribe to the Youtube channel, every little bit helps. As always, I’m happy to see comments and will comment back as soon as I see them.

Thanks for visiting and Happy Rovering.

Reviewing the Painting of the Interior Trim (Post #628) October 16, 2023

I painted the interior trim last year. I didn’t publish it…not sure why. Anyway, I cover some of the details of painting the interior trim while looking like Kip from Kip’s Big Boy fame. We had a Kip’s in OKC 40+ years ago…I remember eating there once.

Anyway…I guess I hadn’t looked in the mirror that day and my hair is doing it’s own thing. And apparently I can’t dress myself either. I’m slowly moving toward “crazy old man who don’t give a damn” mode.

In this installment I talk about my work on the interior and what might be next. Like stripping the shellac off the wood trim and re-staining it a darker color to match the dark chocolate interior.

I added two USB charging ports that show the voltage from the battery. I don’t smoke in the Big White Bus so I really didn’t need the cigarette lighters. These are way more functional for all the USB powered “everythings” that we all need to carry. I’m fooling myself that I only need four of these. When I wire up the rest of the battery system for the back I’ll have quite a few more that will be pulling from the auxiliary battery I’m planning to have onboard.

It’s a short video shot back in November of 2022.

Thanks for reading and Happy Rovering.
