I started the day with glorious visions of finishing the welding on the Floor Panel. All I managed to accomplish was spectacular failure.
Things that worked:
I had some luck with my homemade plug weld drill bit. It worked well at removing the layers of primer and seam sealer I had foolishly laid down.
Welding. Some of my welds actually held pretty well. I managed to get a good ground and the welds stuck until I stressed them too far. On second thought, maybe that means the welds sucked.
My home made air hammer … hammer bit stretched the metal a lot. But the shape I needed and the one the I got weren’t going to work.
Things that didn’t work:
Welds. As before, they popped when put under a lot of stress.
My understanding of metal working,
My spinal cord did not like the constant bending over.
After I had the panel welded in place I tried to apply my air hammer on the panel to get the metal to stick. I also tried using self tapping screws to get the panel to stay in place. This may have worked better if I had shaped the panel better.
All in all, it was a waste of wire and gas. I’ve since cut the panel down smaller. I cut all the plug welds off. I’ll try edge welding when I start return to make the fix. Changed the way the transmission tunnel weld was fixed. It’s now straighter less “bowl shaped”. I’m pretty sure I’ll need help holding the panel in place while I make the first few welds.
We got a big break in the weather. A cold front hit and we got a lovely lightning show along with the fireworks. And we got some cooler weather. The shop wasn’t crazy hot today and won’t be all weekend. So I’m going to take advantage of it and get some work done.
In this post my goal was to get the floor pan welded up. I first had to fix a small patch to the bottom corner. I made a template and got the steel cut. It welded up pretty well. I was pretty happy with the results.
Then I started on the floor panel. I first drilled some holes for the plug welds. This reinforced my need for a drill press. I really want a drill press.
Due to the odd shape of the floor. My panel does not fit very well. Off camera I tried several things to get the panel to line up and contour to the floor. I didn’t have much success. And getting the panel to stay put while I welded, well, I was trying to hold it and weld it. I struggled greatly.
So I decided to put a few self-tapping screws in the panel. These held the panel as expected. I put my hand-made plug weld bit to good use and started welding. I had some success all across the bottom. I didn’t have much luck with the welds near the transmission tunnel but I did finally get some welds to stick.
At this point I realized my welding helmet stopped darkening. This could have gone really badly for me. I did weld two plugs without darkening. I’m glad I noticed, because that kind of eye damage is the real deal.
At this point I’m going to used the self tapping screws to pull the two panels together. I’ll make the plug welds in the holes and then pull the self tapping screws and fill those with welds. At least I have a plan and I am relatively confident this will work.
I’ll then fill the gap on the bottom side with seal sealer. Paint everything with a couple more coats and then I’ll seal it all up with rattle can truck bed liner.
In this post I talk about making my replacement panel for the front passenger side wheel well. I went to Chickasha Industrial and bought a piece of scrap 20 gauge. It will be just the right amount for the fender and the floor panel. Happy I didn’t have to buy a giant sheet.
I started by making my measurements and then checking them again. After I finished that I checked the measurements again. In the video I show how I needed to have a trapezoid shape. And after typing trapezoid in this post I realize I have spelled it wrong in this post, which is being exported as I type up this post. Oh well…..
I referenced “Mephisto’s Trapezoid” from the 1981 Pee Wee Herman – Live at the Roxy show which was on HBO. It’s one of my favorite shows to watch and was the inspiration for Pee Wee’s Playhouse. Captain Carl, played by the amazing Phil Hartman, tells his story to Pee Wee about getting lost in Mephisto’s Trapezoid. Comedic genius.
I cut the steel and then measured again. I made some bends to get the inner edge and the back lip right. After getting the panel made I could tell I needed to make some adjustments to the fender well too. So I did some hammer and dolly work and got everything sorted. I also had to adjust my panel after I got everything sorted. No biggy.
I dry fitted the panel at least six times. I’m pretty sure I can get it into place with just a few plug welds. I’m going to try my hand tomorrow at modifying a broken drill bit to make a plug weld bit. If that doesn’t produce results I’ll probably run to a welding shop and see what I can find. The gist of this is you can paint everything and seal it with whatever then remove just the part of the paint you need to weld.
This is a giant experiment because the entire floor pan in the back is going to be done this way. The holes are there and all I’ll need to do is get the Z bar in place and make a crap ton of plug welds. Then I can get the entire seam sealed with bedliner and or whatever.
In this installment I apply seam sealer to the most recently welded “L”. Seam sealer was not how I wanted to seal this joint up. I wanted it to be welded closed. That is just not possible. It wasn’t originally built that way. I can only hope the seam sealer I’m using will last long enough for me to quit this Overlanding Hobby.
I also look at the floor patch I’m going to need to build. I talk about the two structural bends in the panel. I saw the guy on Make It Kustom [Youtube] build a jig and a tool to make these kinds of bends. You can look through his videos to find it. I’m going to think long and hard about this before I tackle this problem.
It might be fun to build the jig. I will need to buy a router bit to get the jig in the right shape. I’ll probably need to build a special air hammer bit like he did too. It would be a one off fix. I don’t think I will ever tear this apart again.
It’s a short video and I know it’s über riveting content watching me smear seam sealer. In my defense I didn’t have time to produce anything else this weekend. Saturday we visited the Evil German Dude and his lovely wife. Paparazzi Ford was there too. The Evil German Broad made brunch for us and we all got to catchup on the latest happenings and see their almost finished “cabana”. That’s what the county commissioners called it for tax purposes.
It’s an amazing space and it took a lot of forethought, planning, engineering to make it as awesome as it is. Several things I saw had me comparing how much time I’ve spent thinking about the future state of the Big White Bus. I know I’ll have some great ideas that will need additional thought and probably re-engineering to get them right.
I picked up a parts washer from EGD too while I was there. So that’s pretty cool. That’s all for this week. Like and subscribe to the blog and the Youtube channel.
The good news…I have the swimming pool setup and I’ve been in it twice this weekend.
The bad news…I still suck at welding. In my defense this part of the Range Rover Classic is a mish-mash of panels converging into a very small space. There are no less that three different pieces in this area that are plug welded and the gaps filled with seam sealer. In a future video when I build the rest of of the upper wheel well, I will point out the three layers of panels that go into building the wheel well. It’s so convoluted that screws were even used to hold the parts together. SCREWS!
Anyway. I build my replacement parts and attempted to get them married together. Ironically I have three pieces of metal to get this done. Well four if you count the patch of the side bulkhead.
Did I say it was hard to weld under there? NO? Well it’s damn hard to weld under there. You have basically two positions. Mashed up against the wheel hub and laying on the ground with welding slag (molten metal) falling on you. Both, super awesome as you can well imagine.
I said I was swimming earlier in this post. While sitting on the patio drying off Mrs. Okierover noted the weird red scratches on my right arm. I told her they were from being mashed up against the hub.
Manufacturing the repair pieces was a bit of folly too. I had to make the “L” three times. First time was an experiment to see if I could make a bended L. The second was because I measured the piece without the floor panel in the right place. The third time was a charm or I decided that was going to be the last time I made it and I made it work.
Don’t get me wrong, careful thought was expended. A LOT of thought. And in the end I was still wrong but not by much.
With a lot of clamping and grinding and grunting I have the pieces welded together. The welds are ugly. A lot of seam sealer will be used to discourage water from coming in these seams. Probably about as much as was used by the factor but the difference is my metal is covered with primer. Theirs was not. To protect this section I will rely on primer, at least three coats. Rust encapsulator will also be liberally applied. And over that, rhino/bed liner. Inside the cab will also be a layer of Fat Mat.
Will all this work and product prevent rust? Probably not. Who are we kidding? The Range Rover Classic was built to rust. The goal was that it rusted out on the second or third owner. I had the added bad luck that my Range Rover was a victim of a front end wreck before I owned it. Sports and Classics did the best they could to weld a donor front end on to the rear half. And I’m doing my best to keep rust at bay the best I can.
There were 19 segments filmed over two days. I left a lot of the welding out of the video. Mostly because it was difficult enough for me to get into place to weld, there really wasn’t any room for a camera.
It was hot in the shoppe too. Temps at or above 100F (37.8 C for those of you living in countries that have never had a man on the moon). The camera overheats when I’m filming in these temps. So the camera sat on the air conditioner when I wasn’t filming. I wonder if anyone makes a camera that can do warmer temps? My next camera will be evaluated for temps.
This weekend was Memorial Day. Freedom is not free. So many have given everything they had to keep you free. Remember those and their great sacrifice.
In this installment I begin the disassembly of the front fender to expose more rust. And I was NOT disappointed. I found just about what I expected. A rusted through footwell. On a positive note…I think I found where the water was getting in to soak my carpets. I have no idea how to correct it, but at least I found it.
In order to get to all the rust the front fender had to come off. I encountered a bunch of rusted screws and bolts. I had to cut several of them off. I even used an air chisel to remove some spring type U nuts (yeah I had to look that name up, I had no idea what they were called). I can tell you they were a bitch to remove. But after you deconstruct them a bit they came right off. I’ll likely replace the U nuts with stainless steel bolts and nuts.
The fender didn’t put up much resistance after I got the U nuts off. I then had to remove a plastic fender piece. You can probably guess that the plastic clips weren’t going to survive being taken off.
Underneath I found a lot of surface rust. I put the angle grinder with a wire wheel to work. I cleaned up some of the rust and found a bunch of really bad metal.
In the seem between the wheel well and the footwell I found what I think is the source of my wet carpets. This spot is going to be hard to fix. I don’t know what needs to be cut away and what needs to be welded on.
Inside where this failed bulkhead is is covered with Fat Mat. That will need to be removed. Heat gun and patience I hope will assist me in getting it removed. There is a nice cluster of wires and relays right there too. So joy of joys I’ll get to relocated all that too!!! Woot!
I also took the lug nuts and cleaned all the rust off them. I have the first coat of paint on them. They’ll get a second before I put them back on.
That’s about it for this week. I got to watch some severe weather out in western Oklahoma on Sunday. It all petered out before it got to the Okierover Base Camp.
